Built a direct-to-storage batch upload system where photographers can process hundreds of private school photos in the browser without server image work.
Tech stack
Responsibilities
System architecture
Designed the control-plane / data-plane split so uploads never touch the application server's CPU or memory.
Upload UX
Built the large-batch drop experience with one batch toast, parallel uploads, and weighted monotonic progress.
Web Worker image processing
Implemented the singleton Canvas worker that resizes and watermarks previews with bounded memory.
Storage security
Owned presign authorization, server-named keys, and forged-key rejection at registration.
Test strategy
Covered the trust boundary with integration and unit tests across upload, storage, and watermarking.
01 - System shape
Uploading had to protect private originals, avoid server image work, preserve tenant boundaries, and make a large drop feel like one operation.
Problem
Parents must only see watermarked, downsized previews; originals are inventory for paid delivery.
Decision
Split originals and previews into separate storage objects and register only preview keys into gallery assets.
Result
Galleries surface the proof path, while originals remain behind the paid signed-link delivery flow.
Problem
Server-side transforms would push hundreds of large images through a Cloudflare Worker runtime.
Decision
Use the server as the control plane and object storage as the data plane through short-lived presigned PUT URLs.
Result
Upload volume no longer scales application CPU, memory, or image-transform spend.
Problem
A browser can create bytes, but it cannot decide tenant ownership.
Decision
Server-name keys under creator and gallery prefixes, then re-check ownership and key prefix at registration.
Result
Forged cross-tenant writes are rejected before any asset row becomes visible.
02 - Architecture
Read left to right: the browser and object storage carry the image bytes, the app server only authorizes and records, and the database is the final gate on what becomes visible.
Carries the image bytes. Processes and uploads pixels, but is never trusted to decide ownership.
Holds the authority. Authorizes each upload and names the keys, but never streams a single pixel.
Owns visibility. Storage keeps the bytes; the database decides what a gallery is actually allowed to show.
03 - Decision
Why plausible
One implementation path for local MinIO and production R2, no transform fees, and no Worker CPU pressure.
Outcome
Chosen because photographers are watermarking their own proofs, while paid originals stay behind separate signed delivery links.
Why plausible
Could keep processing deterministic without a separate image service.
Outcome
Rejected as more operational surface than Canvas for JPEG previews, without changing the trust model.
Why plausible
A stronger enforcement point if uploaders become untrusted or HEIC/RAW support becomes necessary.
Outcome
Kept as a documented one-to-two-day exit plan because it adds transform cost and runtime-specific code paths.
04 - Trust boundary
Client-side processing is acceptable only because visibility is created later, at registration, inside the server-controlled boundary.
Browser may claim
Selected filename, MIME type, and size.
Server verifies
Zod shape, content-type allowlist, 50 MB max file size, and 100 files per presign batch.
Browser may claim
Requested gallery target.
Server verifies
Authenticated actor and gallery ownership before presigning.
Browser may claim
Uploaded preview bytes.
Server verifies
Preview objects are not visible until registration writes an asset row.
Browser may claim
Storage key returned from the client.
Server verifies
The key must decode to the same creator as the target gallery.
05 - Implementation
The tab can upload bytes to a presigned URL, but it cannot forge tenant ownership by posting an arbitrary key.
01export async function registerUploadedAsset(input: RegisterAssetInput) {02 // The tab can PUT bytes to a presigned URL, but the key it hands back is untrusted.03 const { creatorId: expectedCreatorId } = await validateUploadGallery(input);04 const keyCreatorId = extractCreatorIdFromKey(input.storageKey);05 06 if (keyCreatorId !== expectedCreatorId) {07 throw new Error("storageKey creator prefix does not match the gallery's creator");08 }09 10 // Only now, inside the verified boundary, does the asset become visible.11 return insertAsset(input, expectedCreatorId);12}06 - Flow and evidence
The browser posts gallery and file metadata to the presign route.
The server verifies the actor, gallery ownership, limits, and content types, then returns original and preview PUT URLs with server-named keys.
The original streams directly to object storage while a singleton Web Worker creates the watermarked JPEG preview.
The browser uploads the preview and asks the server to register the asset.
The server re-verifies ownership, rejects forged prefixes, inserts the asset row, writes audit data, and records billing counters best-effort.
Folder structure
docs/// Design record and exit plansrc/├── app/api/upload/// Presign API boundary├── server/│ ├── storage/// Storage contract│ ├── admin/// Registration boundary│ └── creator/// Registration boundary├── workers/// Watermark worker pipeline├── lib/watermark/// Watermark worker pipeline├── stores/// Upload state and orchestration└── components/shared/upload/// Upload state and orchestrationtests/├── integration/│ ├── upload/// Integration coverage│ └── storage/// Integration coverage└── unit/ ├── watermark/// Unit coverage └── upload/// Unit coverage07 - Outcome
The application server authorizes and records uploads instead of proxying or transforming hundreds of image files.
Watermarked previews and paid originals became separate storage objects with different visibility paths.
Actor checks, tenant-prefixed keys, prefix validation, and RLS-backed transactions prevent cross-tenant asset visibility.
A singleton Worker, parallel original PUTs, one batch toast, and weighted monotonic progress keep big drops understandable.
